Gen Series
Along with our renown quality, GenSteel clients can count on a wide selection of doors from which to choose. Our signature Gen Series meets all the needs of builders and developers, whether it be design, safety or security — or all three. Click through the options below.
| Tough to the CoreTM Gensteel offers a full range of standard hollow metal doors, embossed doors, custom lite doors, stainless steel doors, fire rated doors, hurricane resistance doors, tornado resistance doors, welded or knock-down steel door frames and more. We offer a wide selection of standard, ready-to-ship products as well as custom architectural, engineered products to fulfill any construction design and application. Doors are 1¾ inch thick and are available in 14, 16, 18, and 20 gauge. Custom made stainless steel, lead-lined (x-ray) and G90 galvanized steel doors are also available. |
| Tough to the CoreTM Gensteel offers a full range of standard hollow metal doors, embossed doors, custom lite doors, stainless steel doors, fire rated doors, hurricane resistance doors, tornado resistance doors, welded or knock-down steel door frames and more. |
- 32% more break-in resistantBreak-in resistance was measured with an impact weight of 9.3 lb dropped on the door at the latch point from incremental heights until the latch yielded under impact. (Test inspired by ASTM D-1037-99)
- 20% more deflection resistantDeflection was tested by incremental weights loaded on an I-beam across the width of the horizontally-installed door. (Test inspired by ASTM C-203-99)
- 30% more delamination resistantThe delamination test involved pull suction on both sides of the door at the same time, followed by a tensile test until delamination occured. (Test inspired by ASTM C-297-04)
- 37% better resistant to twistingIn the twist test, the door was supported at three points while the free corner was incrementally loaded with weights.
- No. 1 for corrosion resistanceCorrosion resistance to regular basic salt spray was measured on a 6″ x 6″ section of the door installed in a salt spray cabinet for 72 hours. (Test performed as per ASTM B-117-03)
- G–10 WarrantyGensteel doors come with an unrivalled 10-year warranty against delamination and a two-year warranty against material and/or workmanship defects.
| Galvannealed Steel Galvannealed steel is coated with a Zinc-Iron Alloy by a process known in the metallurgical technology, as the Hot-Dip Process. This process consists of passing cold reduced sheet steel in coil form continuously through a pot of molten zinc. As the steel leaves the pot, the amount of coating allowed to remain on the sheet is controlled by coating rolls which are used to establish minimum coating weights in accordance to ASTM Designation A525/A525M. The zinc coating is what protects the steel against corrosion. This protection acts in two ways. The zinc acts as a shield between the base steel and the atmosphere and when the base steel is exposed, such as at sheared or blanked edges, the zinc acts as a galvanic protector, sacrificing itself in the presence of corrosive elements. The coating structure consists of a layer of zinc superimposed on a thin alloys layer consisting of both iron and zinc. The solidification of the zinc layer results from crystallization of the bath metal. |
| Galvannealed Steel Galvannealed steel is coated with a Zinc-Iron Alloy by a process known in the metallurgical technology, as the Hot-Dip Process. This process consists of passing cold reduced sheet steel in coil form continuously through a pot of molten zinc. As the steel leaves the pot, the amount of coating allowed to remain on the sheet is controlled by coating rolls which are used to establish minimum coating weights in accordance to ASTM Designation A525/A525M. The zinc coating is what protects the steel against corrosion. |
Why Galvannealed Steel?
- Competitive purchase cost
- Reduced preparation and painting costs
- Longer life-expectancy
- Excellent resistance to corrosion
- Superb paint adhesion characteristics
- Requires minimal maintenance
Wood Grain Finishes & Powder Coating
Introducing a new line of decorative simulated wood grain steel doors offering a powerful blend of aesthetics with performance. In addition, we also offer an unlimited choice of powder coating.
Advantages over wooden doors
Advantages over wooden doors
-
Fire protection
Available with a fire protection rating of up to 3 hours. -
No swelling, rot or warp
Steel doors will not swell, rot or warp. -
Highly resistant
Highly resistant to UV Rays, corrosion, termites, and insects. -
Durable finish
More consistent and durable finish.
